5SL B 10A 1P OVERCURRENT CIRCUIT BREAKER B 10A 1M 10KA

Name: 5SL B 10A 1P OVERCURRENT CIRCUIT BREAKER B 10A 1M 10KA
Brand: SIEMENS
SKU: 892949
Availability: InStock

6,20 € VAT incl.

VAT incl. (21%)

RRP price: 11,94 €

Part No: 5SL4110-6

Brand: SIEMENS

6 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,1 kg
Dimensions	60 × 50 × 10 mm
Voltage type	AC
Built-in depth	70mm
Rated current	10A
Rated voltage	400V
Frequency	50Hz
Release characteristic	B
Rated insulation voltage Ui	-99999V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	1
Degree of protection (IP)	IP20
Connectable conductor cross section solid-core	0.75mm2
Connectable conductor cross section multi-wired	0.75mm2
Ambient temperature during operating	-25°C
Number of poles (total)	1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Brand	SIEMENS
SKU	892949
EAN	4001869439228
