5SL B 20A 3P OVERCURRENT CIRCUIT BREAKER B 20A 3M 6KA

Name: 5SL B 20A 3P OVERCURRENT CIRCUIT BREAKER B 20A 3M 6KA
Brand: SIEMENS
SKU: 788842
Availability: InStock

19,19 € VAT incl.

VAT incl. (21%)

Part No: 5SL6320-6

Brand: SIEMENS

10 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,452 kg
Dimensions	110 × 100 × 100 mm
Voltage type	AC
Built-in depth	70mm
Rated current	20A
Rated voltage	400V
Frequency	50Hz
Release characteristic	B
Rated insulation voltage Ui	-99999V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	3
Degree of protection (IP)	IP20
Connectable conductor cross section solid-core	0.75mm2
Connectable conductor cross section multi-wired	0.75mm2
Ambient temperature during operating	-25°C
Number of poles (total)	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	6kA
Brand	SIEMENS
SKU	788842
EAN	4001869388878
