5SU1 B16A/ 30MA/AC 1P+N DIFFERENTIAL CURRENT SWITCH B16A 30MA 2M AC 10KA

Name: 5SU1 B16A/ 30MA/AC 1P+N DIFFERENTIAL CURRENT SWITCH B16A 30MA 2M AC 10KA
Brand: SIEMENS
SKU: 788941
Availability: InStock

39,48 € VAT incl.

VAT incl. (21%)

RRP price: 94,16 €

Part No: 5SU1354-0KK16

Brand: SIEMENS

2 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,05 kg
Dimensions	100 × 80 × 40 mm
Voltage type	AC
Built-in depth	70mm
Rated current	16A
Rated voltage	230V
Release characteristic	B
Rated insulation voltage Ui	264V
Rated fault current	0.03A
Leakage current type	AC
Surge current capacity	1kA
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	2
Degree of protection (IP)	IP20
Number of protected poles	1
Rated short-circuit breaking capacity according to EN 60898	10kA
Rated short-circuit breaking capacity according to IEC 60947-2	20kA
Connectable conductor cross section solid-core	0.75mm2
Connectable conductor cross section multi-wired	0.75mm2
Number of poles (total)	2
Rated impulse withstand voltage Uimp	4kV
Rated short-circuit breaking capacity Icn according to EN 61009-1	10kA
Disconnection characteristic	Undelayed
Rated short-circuit breaking capacity according to EN 61009	10kA
Brand	SIEMENS
SKU	788941
EAN	4001869307589
