ADC970D/AD970B C20A/ 30MA/AC 1P+N DIFFERENTIAL CIRCUIT BREAKER C20A 2M 30MA AC 6KA

Name: ADC970D/AD970B C20A/ 30MA/AC 1P+N DIFFERENTIAL CIRCUIT BREAKER C20A 2M 30MA AC 6KA
Brand: HAGER
SKU: 521472
Availability: InStock

62,10 € VAT incl.

VAT incl. (21%)

RRP price: 157,84 €

Part No: ADC970D

Brand: HAGER

1 in stock

Add to wishlist

Compare

Delivery

Delivery time 3-5 working days.

50k products

For your home.

Support

Fast support.

Quality

Top product brands.

Description

RCBO WYŁĄCZNIK RÓŻNICOWOPRĄDOWY Z CZŁONEM NADPRĄDOWYM 1P+N 6KA C 20A/30MA TYP AC

Additional information

Weight	0,226 kg
Dimensions	100 × 80 × 40 mm
Voltage type	AC
Built-in depth	68mm
Rated current	20A
Rated voltage	240V
Release characteristic	C
Rated insulation voltage Ui	500V
Rated fault current	0.03A
Leakage current type	AC
Surge current capacity	0.25kA
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	2
Frequency	50 Hz
Degree of protection (IP)	IP20
Number of protected poles	1
Rated short-circuit breaking capacity according to EN 60898	6kA
Rated short-circuit breaking capacity according to IEC 60947-2	6kA
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	2
Rated impulse withstand voltage Uimp	4kV
Rated short-circuit breaking capacity Icn according to EN 61009-1	6kA
Disconnection characteristic	Undelayed
Brand	HAGER
SKU	521472
EAN	3250611063827
