AZ C80A OVERCURRENT CIRCUIT BREAKER C80A 3M 20KA

Name: AZ C80A OVERCURRENT CIRCUIT BREAKER C80A 3M 20KA
Brand: EATON
SKU: 974250
Availability: InStock

175,97 € VAT incl.

VAT incl. (21%)

RRP price: 508,14 €

Part No: 211801

Brand: EATON

18 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,25 kg
Dimensions	75 × 90 × 81 mm
Voltage type	AC
Built-in depth	75mm
Rated current	80A
Rated voltage	400V
Frequency	50Hz
Release characteristic	C
Rated insulation voltage Ui	440V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	4.5
Degree of protection (IP)	IP20
Number of protected poles	3
Connectable conductor cross section solid-core	2.5mm2
Connectable conductor cross section multi-wired	2.5mm2
Ambient temperature during operating	-25°C
Number of poles (total)	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	20kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	20kA
Rated impulse withstand voltage Uimp	4kV
Brand	EATON
SKU	974250
EAN	4015082118013
