DEHNGUARD S 275 T2 B 1P 1M 20/40KA 1.5KV SURGE ARRESTER

Name: DEHNGUARD S 275 T2 B 1P 1M 20/40KA 1.5KV SURGE ARRESTER
Brand: DEHN
SKU: 058532
Availability: InStock

101,64 € VAT incl.

VAT incl. (21%)

Part No: 952070

Brand: DEHN

23 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

32650/B OCHRONNIK DEHN QARD S275 (DGT) 952070 952070 SZT SI

Additional information

Weight	0,13 kg
Dimensions	75 × 105 × 22 mm
Mounting method	DIN rail (top hat rail) 35 mm
With remote signalling contact	No
Number of conductors (without earthing)	1
Construction size	1 modular spacing
Voltage protection level	1.5kV
Max. continuous voltage AC	275V
Nominal discharge surge current (8/20)	20kA
Nominal voltage AC	230V
Signalling at the device	Optical
Max. continuous voltage DC	350V
Degree of protection (IP)	IP20
Max. conductor cross section solid (solid, stranded)	35mm2
Max. conductor cross section flexible (fine-strand)	25mm2
Max. discharge surge current (8/20)	40kA
Short-circuit breaking capacity (Isccr)	50kA
Max. overcurrent protection device, parallel connection (fuse)	125A
Max. overcurrent protection device, series connection (fuse)	100A
Brand	DEHN
SKU	058532
EAN	4013364108493
