DILEM12-01-EA 12A 3Z 1R POWER CONTACTOR 12A 3Z 1R 5.5KW 230V AC SCREW TERMINALS

Name: DILEM12-01-EA 12A 3Z 1R POWER CONTACTOR 12A 3Z 1R 5.5KW 230V AC SCREW TERMINALS
Brand: EATON
SKU: 729022
Availability: InStock

27,25 € VAT incl.

VAT incl. (21%)

RRP price: 53,60 €

Part No: 189989

Brand: EATON

8 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,176 kg
Dimensions	58 × 48 × 46 mm
Rated operation power at AC-3, 400 V	5.5kW
Number of normally open contacts as main contact	3
Number of normally closed contacts as main contact	0
Number of auxiliary contacts as normally open contact	0
Number of auxiliary contacts as normally closed contact	1
Rated operation current Ie at AC-3, 400 V	12A
Rated operation current Ie at AC-1, 400 V	22A
Rated control supply voltage AC 50 Hz	230V
Rated control supply voltage AC 60 Hz	240V
Rated control supply voltage DC	0V
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	AC
Rated operation current Ie at AC-4, 400 V	6.6A
Rated operation power at AC-4, 400 V	3kW
Rated operation power NEMA	3.7kW
Brand	EATON
SKU	729022
EAN	4015081879854
