Weight	11,135 kg
Dimensions	600 × 600 × 200 mm
Core identification	Colour
Weight	37kg/km
Stranding element	Pairs
Category	5E
Conductor material	Copper
Screen over stranding element	None
Screen over stranding	None
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 1 = solid
Armouring/reinforcement	None
Protective sheath	Polyvinyl chloride (PVC)
Number of cores	8
Stranding	Bundle
Outer diameter approx.	6.2mm
NVP value	71%
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
AWG size	24
Min. permitted bending radius, moving application with forced guidance	62mm
Min. permitted bending radius, moving application/free movement	62mm
Min. permitted bending radius, stationary application/permanent installation	50mm
Specification core insulation	Other
Material armouring	Other
Cable geometry	Round
Approved type of underground installation	Other
Brand	C&C PARTNERS
SKU	3089239
EAN	5904169100005

DOMNET CABLE F/UTP CAT 5E PVC 305M
