Weight	0,144 kg
Dimensions	155 × 120 × 35 mm
Nominal voltage	230V
Mounting method	Surface mounted
Color	White
Model	Movement sensor
Connection type	Screwed terminal
Surface protection	Other
Voltage type	AC
Switching-on delay	1s
Switch-off delay	0s
Built-in depth	0mm
Frequency	50Hz
Diameter	115mm
Built-in width	0mm
Built-in diameter	0mm
Material quality	Thermoplastic
Max. reach frontally	8m
Max. reach sideways	8m
Max. switching power	800W
Temperature	-25°C
Max. starting current	10A
pa_material	Plastic
Response value luminosity	3lx
Diameter reach on floor	16m
RAL-number (similar)	9003
Scan angle	360°
Built-in length	0mm
Impact strength	IK00
Degree of protection (IP)	IP20
Surface finishing	Matt
Detection angle horizontal	360°
Min. switch-on time	10s
Max. duty cycle	13min
Optimum mounting height	2.8m
Number of switching zones	1
Min. depth of built-in installation box	0mm
Sensor type	Passive infrared
Brand	F&F
SKU	738185

DRM-08 CEILING MICROWAVE MOTION SENSOR WITH PRESENCE FUNCTION
