FRBMM-B10/1N/01 B 10A/ 100MA DIFFERENTIAL OVERCURRENT SWITCH B 10A 1P+N 2M 100MA 10KA

Name: FRBMM-B10/1N/01 B 10A/ 100MA DIFFERENTIAL OVERCURRENT SWITCH B 10A 1P+N 2M 100MA 10KA
Brand: EATON
SKU: 887198
Availability: InStock

75,79 € VAT incl.

VAT incl. (21%)

Part No: 170657

Brand: EATON

1 in stock

Add to wishlist

Compare

Delivery

Delivery time 3-5 working days.

50k products

For your home.

Support

Fast support.

Quality

Top product brands.

Additional information

Weight	0,201 kg
Dimensions	80 × 35 × 75 mm
Voltage type	AC
Built-in depth	75.5mm
Rated current	10A
Rated voltage	240V
Release characteristic	B
Rated insulation voltage Ui	500V
Rated fault current	0.1A
Leakage current type	AC
Surge current capacity	0.25kA
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	2
Frequency	50 Hz
Degree of protection (IP)	IP20
Number of protected poles	1
Rated short-circuit breaking capacity according to IEC 60947-2	15kA
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	2
Rated impulse withstand voltage Uimp	4kV
Rated short-circuit breaking capacity Icn according to EN 61009-1	10kA
Disconnection characteristic	Undelayed
Rated short-circuit breaking capacity according to EN 61009	10kA
Brand	EATON
SKU	887198
EAN	4015081674541
