H03VVH2-F OMYP 2X 0.75 BLACK FLAT SOFT 300/300V RESIDENTIAL CABLE

Name: H03VVH2-F OMYP 2X 0.75 BLACK FLAT SOFT 300/300V RESIDENTIAL CABLE
Brand: ELPAR
SKU: 3045569
Availability: InStock

360,94 € VAT incl.

VAT incl. (21%)

Part No: OMYP-2X0,75CR H03VVH2-F

Brand: ELPAR

Delivery time 3-5 working days.

For your home.

Fast support.

Additional information

Weight	4 kg
Dimensions	200 × 200 × 120 mm
Nominal cross section conductor	0.75mm2
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Nominal voltage U	300V
Stranding element	No
Colour outer sheath	Black
Shape of conductor	Other
Conductor material	Copper
Screen over stranding element	None
Screen over stranding	None
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Permitted cable outer temperature during assembling/handling	-5°C
Nominal voltage U0	300V
Number of cores	2
Suspension element	None
Cable width approx.	5.2mm
Cable height approx.	3.2mm
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	None
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Min. permitted bending radius, stationary application/permanent installation	26mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Flat
Brand	ELPAR
SKU	3045569
EAN	5901854409955
