H05V-K LGY 0.5 BLUE SINGLE CONDUCTOR FLEXIBLE CABLE 300/500V CL.5

Name: H05V-K LGY 0.5 BLUE SINGLE CONDUCTOR FLEXIBLE CABLE 300/500V CL.5
Brand: ELPAR
SKU: 3095590
Availability: InStock

123,23 € VAT incl.

VAT incl. (21%)

Part No: H05V-K-0,5NE LGY

Brand: ELPAR

Delivery time 3-5 working days.

For your home.

Fast support.

Additional information

Weight	0,15 kg
Dimensions	100 × 100 × 50 mm
Nominal cross section conductor	0.5mm2
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Flame retardant	According to IEC/EN 60332-1-2
Circuit integrity	None
Nominal voltage U	500V
Colour outer sheath	Blue
Shape of conductor	Round
Diameter conductor	2mm
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Armouring/reinforcement	None
Permitted cable outer temperature during assembling/handling	-5°C
Core colour	Several
Nominal voltage U0	300V
Number of cores	1
Max. conductor temperature	70°C
Protective barrier	None
Outer diameter approx.	2.1mm
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Min. permitted bending radius, stationary application/permanent installation	8.4mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Brand	ELPAR
SKU	3095590
EAN	5901854403755
