H05V-K LGY 0.75 DARK BLUE SINGLE CONDUCTOR FLEXIBLE CABLE 300/500V CL.5

Name: H05V-K LGY 0.75 DARK BLUE SINGLE CONDUCTOR FLEXIBLE CABLE 300/500V CL.5
Brand: LAPPKABEL
SKU: 087621
Availability: InStock

0,21 € VAT incl.

VAT incl. (21%)

Part No: 4510142

Brand: LAPPKABEL

1000 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,012 kg
Dimensions	1000 × 2 × 2 mm
Nominal cross section conductor	0.75mm2
Material core insulation	Polyvinyl chloride (PVC)
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500V
Conductor material	Copper
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-30°C
Core colour
Nominal voltage U0	300V
Number of cores	1
Outer diameter approx.	2.7mm
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Min. permitted bending radius, stationary application/permanent installation	10.8mm
Specification core insulation	Other
Cable geometry	Round
Brand	LAPPKABEL
SKU	087621
EAN	4044773389135
