H05V-U DY 0.5 CZERWONY PRZEWÓD JEDNOŻYŁOWY DRUT 300/500V KL.1

Name: H05V-U DY 0.5 CZERWONY PRZEWÓD JEDNOŻYŁOWY DRUT 300/500V KL.1
Brand: ELPAR
SKU: 3132468
Availability: InStock

125,13 € VAT incl.

VAT incl. (21%)

Part No: H05V-U-0,5CE DY

Brand: ELPAR

Delivery time 3-5 working days.

For your home.

Fast support.

Additional information

Weight	6 kg
Dimensions	300 × 300 × 150 mm
Nominal cross section conductor	0.5mm2
Core identification	Colour
Weight	6kg/km
Lead sheath	No
Drain wire	No
Nominal voltage U	500V
Shape of conductor	Round
Diameter conductor	2mm
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 1 = solid
Armouring/reinforcement	None
Core colour	Several
Nominal voltage U0	300V
Screen	No
Number of cores	1
Protective barrier	None
Outer diameter approx.	2mm
Low temperature resistant according to EN 60811-504+505+506	No
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
AWG size	20
Nominal cross section conductor (AWG)	1.022kcmil
Min. permitted bending radius, stationary application/permanent installation	8mm
Specification core insulation	Other
Specification material outer sheath	Other
Twisted cores	No
Cable geometry	Round
Conductor resistance at 20 °C	36Ω/km
Identification/coding colour core	Red
Core identification according to HD 308 S2	No
Suitable as installation cable	No
Certified for shipboard application	No
Certified as airport lighting cable	No
Max. tensile strength during installation	0.075kN
Brand	ELPAR
SKU	3132468
EAN	5901854404066
