IC60N D 6A 2P OVERCURRENT CIRCUIT BREAKER D 6A 2M 6KA ACTI 9

Name: IC60N D 6A 2P OVERCURRENT CIRCUIT BREAKER D 6A 2M 6KA ACTI 9
Brand: SCHNEIDER ELECTRIC
SKU: 549447
Availability: InStock

16,19 € VAT incl.

VAT incl. (21%)

RRP price: 37,49 €

Part No: A9F05206

Brand: SCHNEIDER ELECTRIC

1 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

IC60N-D6-2 APARATURA MODUŁOWA ACTI 9

Additional information

Weight	0,228 kg
Dimensions	90 × 70 × 35 mm
Voltage type	AC/DC
Built-in depth	44.5mm
Rated current	6A
Rated voltage	400V
Frequency	50Hz
Release characteristic	D
Rated insulation voltage Ui	500V
Current limiting class	3
Over voltage category	4
Pollution degree	3
Width in number of modular spacings	2
Degree of protection (IP)	IP20
Number of protected poles	2
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-35°C
Number of poles (total)	2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	20kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Rated impulse withstand voltage Uimp	6kV
Brand	SCHNEIDER ELECTRIC
SKU	549447
EAN	3606480441387
