IPRD_DC 40R SURGE ARRESTER T2 C 3P 3M 15/40KA 3KV 800V DC PV ACTI 9

Name: IPRD_DC 40R SURGE ARRESTER T2 C 3P 3M 15/40KA 3KV 800V DC PV ACTI 9
Brand: SCHNEIDER ELECTRIC
SKU: 612335
Availability: InStock

Original price was: 104,77 €.Current price is: 94,22 €. VAT incl.

VAT incl. (21%)

RRP price: 198,44 €

Part No: A9L40271

Brand: SCHNEIDER ELECTRIC

2 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

IPRD_DC 40R SURGE ARRESTER T2 C 3P 3M 15/40KA 3KV 800V DC PV ACTI 9

Additional information

Weight	0,346 kg
Dimensions	90 × 75 × 60 mm
Mounting method	DIN rail (top hat rail) 35 mm
Number of conductors (without earthing)	2
Construction size	3 modular spacing
Voltage protection level	3kV
Nominal discharge surge current (8/20)	15kA
Nominal voltage DC	800V
Voltage protection level L-N	3kV
Signalling at the device	Optical
Max. continuous voltage DC	800V
Degree of protection (IP)	IP20
Max. PV-voltage	800V
Voltage protection level N-PE	3kV
Max. conductor cross section solid (solid, stranded)	35mm2
Max. conductor cross section flexible (fine-strand)	35mm2
Max. discharge surge current (8/20)	40kA
Brand	SCHNEIDER ELECTRIC
SKU	612335
EAN	3606480506666
