K60N C 63A 3P OVERCURRENT CIRCUIT BREAKER C 63A 3M 6KA ACTI 9

Name: K60N C 63A 3P OVERCURRENT CIRCUIT BREAKER C 63A 3M 6KA ACTI 9
Brand: SCHNEIDER ELECTRIC
SKU: 822139
Availability: InStock

32,86 € VAT incl.

VAT incl. (21%)

RRP price: 78,07 €

Part No: A9K02363

Brand: SCHNEIDER ELECTRIC

10 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,05 kg
Dimensions	80 × 80 × 40 mm
Voltage type	AC
Built-in depth	70mm
Rated current	63A
Rated voltage	400V
Frequency	50Hz
Release characteristic	C
Rated insulation voltage Ui	440V
Current limiting class	3
Over voltage category	2
Pollution degree	2
Width in number of modular spacings	3
Degree of protection (IP)	IP20
Number of protected poles	3
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	6kA
Rated impulse withstand voltage Uimp	4kV
Brand	SCHNEIDER ELECTRIC
SKU	822139
EAN	3606481138521
