LE-03M-4Q LICZNIK ENERGI ELEKTRYCZNEJ 3F 4-KWADRANTOWY POMIAR, BEZPOŚREDNI DO 100A RS485+ MODBUS RTU
141,19 € VAT incl.
- VAT excl.
116,69 € VAT excl.
VAT incl. (21%)
5 in stock
Delivery
Delivery time 3-5 working days.
50k products
For your home.
Support
Fast support.
Quality
Top product brands.
Electronic electricity meters are modern devices for precise measurement of electricity consumption. They have functions of remote reading, data recording and communication with management systems. Electronic electricity meters are standard in residential, commercial and industrial buildings. They enable cost control and energy consumption analysis.
| Weight | 0,361 kg |
|---|---|
| Dimensions | 80 × 100 × 77 mm |
| Mounting method |
DRA (DIN-rail adapter) |
| Model |
Direct measurement |
| Suitable for |
Purchase/supply |
| Type of indication |
Digital |
| Power consumption |
1W |
| Frequency |
50Hz |
| Max. current (Imax) |
100A |
| Width in number of modular spacings |
4 |
| Number of counter positions |
6 |
| Type of meter |
Electronic |
| Degree of protection (IP) |
IP51 |
| Type of interface |
RS-485 |
| Energy type |
Effective power and blind power |
| Tariff type |
One-tariff |
| Escapement mechanism |
Yes |
| Calibrated |
Yes |
| Approval |
Measuring Instruments Directive |
| Pulse output |
Electrical |
| Pulse type |
S0 |
| Pulse rate |
1000Imp/kWh (kvarh) |
| Accuracy class |
B |
| Pole type |
Three conductor/four conductor |
| Measurement type load profile |
No |
| Rated voltage (Un) N-L |
160V |
| Rated voltage (Un) L-L |
230V |
| Rated current (In) |
5A |
| Brand | |
| SKU | 3148718 |
| EAN | 5902431679044 |
