MCN332E C 32A 3P OVERCURRENT CIRCUIT BREAKER C 32A 3M 6KA

Name: MCN332E C 32A 3P OVERCURRENT CIRCUIT BREAKER C 32A 3M 6KA
Brand: HAGER
SKU: 045827
Availability: InStock

21,56 € VAT incl.

VAT incl. (21%)

RRP price: 50,52 €

Part No: MCN332E

Brand: HAGER

116 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

82007/D WYŁ.NADPRĄD.3X32A C MC332A OSTEL

Additional information

Weight	0,3 kg
Dimensions	85 × 55 × 75 mm
Frequency	50Hz
Voltage type	AC
Built-in depth	70mm
Rated current	32A
Rated voltage	400V
Release characteristic	C
Rated insulation voltage Ui	500V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	3
Degree of protection (IP)	IP20
Number of protected poles	3
Rated short-circuit breaking capacity according to EN 60898	6kA
Rated short-circuit breaking capacity according to IEC 60947-2	10kA
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Rated impulse withstand voltage Uimp	4kV
Brand	HAGER
SKU	045827
EAN	3250614314001
