NSX , CIRCUIT BREAKER NSX160F MIC2.2 160A 3P, 36KA

Name: NSX , CIRCUIT BREAKER NSX160F MIC2.2 160A 3P, 36KA
Brand: SCHNEIDER ELECTRIC
SKU: 944842
Availability: InStock

571,87 € VAT incl.

VAT incl. (21%)

Part No: C16F32D160

Brand: SCHNEIDER ELECTRIC

1 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	1,86 kg
Dimensions	190 × 110 × 140 mm
Number of auxiliary contacts as normally open contact	0
Number of auxiliary contacts as normally closed contact	0
Rated permanent current Iu	160A
Number of poles	3
Overload release current setting	57A
Number of auxiliary contacts as change-over contact	0
Rated voltage	690V
Degree of protection (IP)	IP40
Position of connection for main current circuit	Front side
Type of electrical connection of main circuit	Screw connection
Type of control element	Rocker lever
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz	36kA
Adjustment range short-term delayed short-circuit release	86A
Adjustment range undelayed short-circuit release	2400A
Device construction	Built-in device fixed built-in technique
Brand	SCHNEIDER ELECTRIC
SKU	944842
EAN	3606481997180
