OTL50-2 GREY 2XAL/CU 1,5-50MM2 1000V UNIVERSAL TERMINAL

Name: OTL50-2 GREY 2XAL/CU 1,5-50MM2 1000V UNIVERSAL TERMINAL
Brand: MOREK
SKU: 124063
Availability: InStock

8,18 € VAT incl.

VAT incl. (21%)

RRP price: 12,61 €

Part No: MAA2050A10

Brand: MOREK

174 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

Złączka szynowa gwintowa rozgałęźna AL, CU, 1.5 – 50mm2, TS 35, 1 tor, 4 otw. zaciskowe_szary_VC05-0016

Additional information

Weight	0,068 kg
Dimensions	47 × 29 × 42 mm
Mounting method	DIN rail (top hat rail) 35 mm
Color	Grey
Rated voltage	1000V
Length	49mm
Inflammability class of insulation material according to with UL94	V0
Width/grid dimension	30mm
Type of electrical connection 1	Screw connection
Number of levels	1
Number of clamp positions per level	4
Connectable conductor cross section fine-strand with cable end sleeve	1.5mm2
Connectable conductor cross section fine-strand without cable end sleeve	1.5mm2
Connectable conductor cross section multi-wired	1.5mm2
Material insulation body	Thermoplastic
Connection position	Sideways
Rated current In	320A
Brand	MOREK
SKU	124063
EAN	4744397014061
