Weight	0,076 kg
Dimensions	95 × 30 × 30 mm
Switching function	Quick-break switch
Rated operation current Ie at AC-15, 230 V	3A
Rated operation current Ie at DC-13, 230 V	0.27A
Housing material	Plastic
Suitable for safety functions
Coating housing	Other
With status indication
Type of interface for safety communication	None
Type of electric connection	Cable entry PG
Explosion safety category for gas	None
Explosion safety category for dust	None
Construction type housing	Cuboid
Degree of protection (IP)	IP65
Forced opening
Number of safety auxiliary contacts	0
Type of control element	Square roller lever
Type of interface	None
Output electronic
Rated operation current Ie at AC-15, 125 V	6A
Rated operation current Ie at AC-15, 24 V	10A
Rated operation current Ie at DC-13, 125 V	0.55A
Rated operation current Ie at DC-13, 24 V	2.8A
Width sensor	30.3mm
Diameter sensor	12.5mm
Height of sensor	30mm
Length of sensor	92mm
Number of contacts as normally closed contact	1
Number of contacts as normally open contact	1
Number of contacts as change-over contact	0
Alignment of the control element	Other
Brand	POKÓJ
SKU	155598
EAN	5902626135461

PAP1 T31 PZ11 LIMIT SWITCH
