PC 16/ 3-STF-10,16 PRINTED CIRCUIT BOARD PLUG CONNECTORS

Name: PC 16/ 3-STF-10,16 PRINTED CIRCUIT BOARD PLUG CONNECTORS
Brand: PHOENIX CONTACT
SKU: 3004000
Availability: InStock

5,70 € VAT incl.

VAT incl. (21%)

Part No: 1967469

Brand: PHOENIX CONTACT

23 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Type of connection	Other
Housing colour	Green
Rated voltage	1000V
Number of poles	3
Contact type	Bus
Housing material	Other
Operating temperature	-40°C
Inflammability class of insulation material according to with UL94	V0
Rated surge voltage	6kV
Type of electric connection	Screw connection
Material of contact surface	Silver
Over voltage category	III
Pollution degree	2
Connectable cable type	Tubular cable
Modular spacing connections	10.16mm
Number of plug-in contact rows	1
Modular spacing contacts	10.16mm
Connectable conductor cross section solid-core	0.75mm2
Connectable conductor cross section fine-strand with cable end sleeve	0.5mm2
Connectable conductor cross section fine-strand without cable end sleeve	0.75mm2
Material insulation body	Polyamide (PA)
Material contact	Copper
Angle contact/conductor connection	Other
Rated current In	76A
Brand	PHOENIX CONTACT
SKU	3004000
EAN	4017918939328
