PHASE C 2A 1P OVERCURRENT CIRCUIT BREAKER C 2A 1M 15KA

Name: PHASE C 2A 1P OVERCURRENT CIRCUIT BREAKER C 2A 1M 15KA
Brand: EATON
SKU: 023065
Availability: InStock

14,96 € VAT incl.

VAT incl. (21%)

RRP price: 42,30 €

Part No: 278549

Brand: EATON

2 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,12 kg
Dimensions	85 × 17,7 × 73 mm
Frequency	50Hz
Voltage type	AC
Built-in depth	70.5mm
Rated current	2A
Rated voltage	230V
Release characteristic	C
Rated insulation voltage Ui	440V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	1
Degree of protection (IP)	IP20
Number of protected poles	1
Rated short-circuit breaking capacity according to EN 60898	10kA
Rated short-circuit breaking capacity according to IEC 60947-2	15kA
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	15kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	15kA
Rated impulse withstand voltage Uimp	4kV
Brand	EATON
SKU	023065
EAN	4015082785499
