PHASE-DC C 10A 2P OVERCURRENT CIRCUIT BREAKER C 10A DC 2M 15KA
50,55 € VAT incl.
- VAT excl.
41,78 € VAT excl.
VAT incl. (21%)
Part No:
279138
Brand:
EATON
15 in stock
Delivery
Delivery time 3-5 working days.
50k products
For your home.
Support
Fast support.
Quality
Top product brands.
Additional information
| Weight | 0,24 kg |
|---|---|
| Dimensions | 85 × 35,4 × 73 mm |
| Frequency |
50Hz |
| Voltage type |
DC |
| Built-in depth |
70.5mm |
| Rated current |
10A |
| Rated voltage |
250V |
| Release characteristic |
C |
| Rated insulation voltage Ui |
440V |
| Current limiting class |
3 |
| Over voltage category |
3 |
| Pollution degree |
2 |
| Width in number of modular spacings |
2 |
| Degree of protection (IP) |
IP20 |
| Number of protected poles |
2 |
| Rated short-circuit breaking capacity according to EN 60898 |
0kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 |
10kA |
| Connectable conductor cross section solid-core |
1mm2 |
| Connectable conductor cross section multi-wired |
1mm2 |
| Ambient temperature during operating |
-25°C |
| Number of poles (total) |
2 |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V |
0kA |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V |
0kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V |
10kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V |
10kA |
| Rated impulse withstand voltage Uimp |
4kV |
| Brand | |
| SKU | 151673 |
| EAN | 4015082791384 |
