PHASE Z 1A 3P OVERCURRENT SWITCH Z 1A 3M 15KA

Name: PHASE Z 1A 3P OVERCURRENT SWITCH Z 1A 3M 15KA
Brand: EATON
SKU: 054255
Availability: InStock

91,44 € VAT incl.

VAT incl. (21%)

Part No: 278919

Brand: EATON

2 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,36 kg
Dimensions	85 × 53,1 × 73 mm
Frequency	50Hz
Voltage type	AC
Built-in depth	70.5mm
Rated current	1A
Rated voltage	400V
Release characteristic	Z
Rated insulation voltage Ui	440V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	3
Degree of protection (IP)	IP20
Number of protected poles	3
Rated short-circuit breaking capacity according to EN 60898	0kA
Rated short-circuit breaking capacity according to IEC 60947-2	10kA
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Rated impulse withstand voltage Uimp	4kV
Brand	EATON
SKU	054255
EAN	4015082789190
