PILA RC007B LED 40S/840 PSU W60L60 CEILING LUMINAIRE LED PANEL LED PT 40W 4000K 4000LM IP20 NIGHT
20,49 € VAT incl.
- VAT excl.
16,93 € VAT excl.
VAT incl. (21%)
Part No:
911401879584
Brand:
PHILIPS FAREL
307 in stock
Delivery
Delivery time 3-5 working days.
50k products
For your home.
Support
Fast support.
Quality
Top product brands.
Additional information
| Weight | 1,61 kg |
|---|---|
| Dimensions | 605 × 605 × 35 mm |
| Protection class |
I |
| Lamp holder |
Other |
| Conductor cross section |
0.75mm2 |
| Connection type |
Other |
| Housing colour |
White |
| Voltage type |
AC |
| Type of grid |
None |
| Type of control gear |
LED operating device current-controlled |
| Colour rendering index CRI |
80-89 |
| Built-in width |
595mm |
| Number of poles |
3 |
| Length |
595mm |
| Height/depth |
33mm |
| Housing material |
Steel |
| Lamp type |
LED not exchangeable |
| Built-in length |
595mm |
| Light outlet |
Direct |
| Light sharing |
Symmetric |
| Material cover |
Plastic, opal |
| Impact strength |
IK02 |
| Nominal voltage |
220V |
| Degree of protection (IP) |
IP20 |
| Beam angle |
Open beam/diffuse |
| Power factor |
0.9 |
| Nominal current |
200mA |
| Colour temperature |
4000K |
| Max. system power |
40W |
| Rated luminous flux according to IEC 62722-2-1 |
4000lm |
| Colour of light |
White |
| Type of wiring |
Ending |
| Colour consistency (McAdam ellipse) |
SDCM5 |
| Total harmonic distortion |
20 |
| Photobiological safety according to EN 62471 |
RG0 |
| Rated ambient temperature according to IEC 62722-2-1 |
25°C |
| Filament test according to IEC 60695-2-11 |
650 °C – 30 s |
| Light distributor |
Diffuser lens/optic/panel |
| Luminaire efficacy |
100lm/W |
| Built-in height/depth |
120mm |
| Surface protection housing |
Powder coating |
| Unified Glare Ratio (UGR) |
25 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) |
40 |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) |
24 |
| Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq) |
70% |
| Failure rate at median useful life of 35,000 h at 25 °C ambient (tq) |
7.5% |
| Flickering value Pst LM |
1 |
| Stroboscope effect value SVM |
1.6 |
| Colour of light adjustable |
No |
| Luminous flux adjustable |
No |
| Beam angle adjustable |
No |
| Brand | |
| SKU | 983103 |
| EAN | 8719514959972 |
