PL7-C4/1-DC C 4A 1P OVERCURRENT CIRCUIT BREAKER C 4A DC 1M 10KA

Name: PL7-C4/1-DC C 4A 1P OVERCURRENT CIRCUIT BREAKER C 4A DC 1M 10KA
Brand: EATON
SKU: 836580
Availability: InStock

24,87 € VAT incl.

VAT incl. (21%)

RRP price: 68,90 €

Part No: 264885

Brand: EATON

4 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,137 kg
Dimensions	75,5 × 17,5 × 80 mm
Voltage type	DC
Built-in depth	70.5mm
Rated current	4A
Rated voltage	220V
Frequency	0Hz
Release characteristic	C
Rated insulation voltage Ui	440V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	1
Degree of protection (IP)	IP20
Number of protected poles	1
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	0kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	0kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Rated impulse withstand voltage Uimp	4kV
Brand	EATON
SKU	836580
EAN	4015082648855
