SPPVT2-10-2+PE SURGE ARRESTER T2 C 2P+PE 3M 15/40KA 3.7KV 1000V DC PV

Name: SPPVT2-10-2+PE SURGE ARRESTER T2 C 2P+PE 3M 15/40KA 3.7KV 1000V DC PV
Brand: EATON
SKU: 617049
Availability: InStock

Original price was: 83,77 €.Current price is: 75,32 €. VAT incl.

VAT incl. (21%)

RRP price: 210,90 €

Part No: 176090

Brand: EATON

3 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

SPPVT2-10-2+PE SURGE ARRESTER T2 C 2P+PE 3M 15/40KA 3.7KV 1000V DC PV

Additional information

Weight	0,336 kg
Dimensions	90 × 53,4 × 65,5 mm
Mounting method	DIN rail (top hat rail) 35 mm
Number of conductors (without earthing)	2
Construction size	3 modular spacing
Voltage protection level	3.7kV
Max. continuous voltage AC	0V
Nominal discharge surge current (8/20)	15kA
Nominal voltage AC	0V
Nominal voltage DC	1000V
Voltage protection level L-N	0kV
Signalling at the device	Optical
Max. continuous voltage DC	1170V
Degree of protection (IP)	IP20
Max. PV-voltage	1170V
Voltage protection level N-PE	0kV
Max. conductor cross section solid (solid, stranded)	35mm2
Max. conductor cross section flexible (fine-strand)	25mm2
Max. discharge surge current (8/20)	40kA
Short-circuit breaking capacity (Isccr)	0kA
Brand	EATON
SKU	617049
EAN	4015081712861
