U/UTP CAT. 5E SECURITYNET OUTDOOR GEL-FILLED PE 500M CABLE
567,24 € VAT incl.
- VAT excl.
468,79 € VAT excl.
VAT incl. (21%)
Part No:
SEC5EUTPG
Brand:
securityNET
Delivery
Delivery time 3-5 working days.
50k products
For your home.
Support
Fast support.
Quality
Top product brands.
Request the product
Additional information
| Weight | 17 kg |
|---|---|
| UV resistant |
Yes |
| Nominal cross section conductor |
0.2mm2 |
| Core identification |
Colour |
| Cable type |
U/UTP |
| Weight |
39kg/km |
| Drain wire |
No |
| Stranding element |
Pairs |
| Category |
5E |
| Diameter conductor |
0.5mm |
| Conductor material |
Copper |
| Screen over stranding element |
None |
| Screen over stranding |
None |
| Material outer sheath |
Other |
| Characteristic impedance |
100? |
| Conductor category |
Class 1 = solid |
| Armouring/reinforcement |
None |
| Number of stranding elements |
4 |
| Protective sheath |
Al/PE |
| Number of cores |
8 |
| Stranding |
None |
| Outer diameter approx. |
5.4mm |
| With rodent protection |
No |
| NVP value |
62% |
| Conductor surface |
Bare |
| Longitudinal water blocking cable |
Yes |
| Radial water blocking cable |
Yes |
| Reaction-to-fire according to EN 13501-6: Class |
Fca |
| Reaction-to-fire according to EN 13501-6: Smoke production |
None |
| Reaction-to-fire according to EN 13501-6: Flaming droplets/particles |
None |
| Reaction-to-fire according to EN 13501-6: Acidity |
None |
| AWG size |
24 |
| Min. permitted bending radius, moving application with forced guidance |
54mm |
| Min. permitted bending radius, moving application/free movement |
54mm |
| Min. permitted bending radius, stationary application/permanent installation |
43mm |
| Specification core insulation |
Polyethylene (PE) |
| Specification material outer sheath |
Polyethylene (PE) |
| Duplex |
Yes |
| Material armouring |
Other |
| Cable geometry |
Round |
| Core identification according to HD 308 S2 |
Yes |
| Suitable as telephone cable |
Yes |
| Suitable as computer data cable |
Yes |
| Suitable as signalling cable |
Yes |
| Certified for shipboard application |
No |
| Max. tensile strength during installation |
0.08kN |
| Segregation class according to EN 50174-2 |
B |
| Approved type of underground installation |
Other |
| Brand | |
| SKU | 3042290 |
| EAN | 5904169100104 |
