WS302 STAIR SWITCH 16A 1Z 1M 250V AC

Name: WS302 STAIR SWITCH 16A 1Z 1M 250V AC
Brand: LEGRAND
SKU: 002667
Availability: InStock

52,26 € VAT incl.

VAT incl. (21%)

RRP price: 96,76 €

Part No: 004707

Brand: LEGRAND

4 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

06397/P WYŁĄCZNIK SCHODOWY WS302 4707 OSTEL

Additional information

Weight	0,09 kg
Dimensions	95 × 85 × 20 mm
Mounting method	DIN rail
Function	Electronic with switching-off pre-warning
Built-in depth	70mm
Release-delay	0.5min
Width in number of modular spacings	1
Control voltage 1	230V
Type of control voltage 1	AC
Frequency control voltage 1	50Hz
Wiring system	3 and 4 wire configuration
Pre-warning of switching-off	Flickering
Repetitive	Repetitive + continuous light + time extension
Voltage type (supply voltage)	AC
Supply voltage	250V
Max. switching current (cos phi = 0.6)	13A
Max. incandescent lamp load	2000W
Max. load fluorescent lamp	1000VA
Max. load fluorescent lamp (Duo circuit)	1000VA
Max. load fluorescent lamp (parallel compensated)	1000VA
Rated switch current	16A
Push button glow-lamp current	50mA
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	1
Number of contacts as change-over contact	0
Brand	LEGRAND
SKU	002667
EAN	3245060047078
