XRUHAKXS 1X 120.0/25.0 RMC BLACK SINGLE CORE CABLE AL 12/20KV CL.2 WITH COAXIAL RETURN CONDUCTOR CU

Name: XRUHAKXS 1X 120.0/25.0 RMC BLACK SINGLE CORE CABLE AL 12/20KV CL.2 WITH COAXIAL RETURN CONDUCTOR CU
Brand: ELPAR
SKU: 973389
Availability: InStock

12054,93 € VAT incl.

VAT incl. (21%)

RRP price: 16500,94 €

Part No: XRUHAKXS-1X120-RMC/25-20KV

Brand: ELPAR

Request the product

Add to wishlist

Compare

Delivery

Delivery time 3-5 working days.

50k products

For your home.

Support

Fast support.

Quality

Request the product

Additional information

Nominal cross section conductor	120mm2
Material core insulation	Other
Core identification	None
Weight	1293kg/km
Nominal voltage U	20kV
Colour outer sheath	Black
Shape of conductor	Round
Conductor material	Aluminium
Material outer sheath	Other
Conductor category	Class 2 = stranded
Permitted cable outer temperature during assembling/handling	-20°C
Number of pilot/reduced conductors	1
Nominal voltage U0	12kV
Nominal cross section concentric conductor	25mm2
Concentric conductor	Copper
Max. conductor temperature	250°C
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Specification core insulation	Crosslinked polyethylene (XLPE)
Specification material outer sheath	Polyethylene (PE)
Cable geometry	Round
Brand	ELPAR
SKU	973389
EAN	5901854436883
