Cable geometry	Round
Specification core insulation	Crosslinked polyethylene (XLPE)
Specification material outer sheath	Other
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Color of coating/insulation	Black
Shape of conductor	Round
Conductor material	Aluminium
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 2 = stranded
Armouring/reinforcement	None
Core insulation material	Other
Core identification	Colour
Protective barrier	None
Core colour	Black
Screen	No
For underground installations	Yes
Halogen-free according to IEC 60754-2	No
Lead sheath	No
Drain wire	No
Twisted cores	No
With protective conductor	No
Number of cores	1
Maximum allowable core temperature	90°C
Permissible ambient temperature of the cable during installation	-5°C
Permissible ambient temperature of the cable after installation (without vibration)	-40°C
Nominal voltage U0	600V
Nominal voltage U	1000V
Nominal cross section conductor	95mm2
Min. permitted bending radius, stationary application/permanent installation	259.5mm
Outer diameter approx.	17.3mm
Weight	450kg/km
Brand	ELTRIM
SKU	991419
EAN	95901564004245

YAKXS 1 x 95RMC 0,6/1kV
