YAKY 5X 35.0 ŻO RE BLACK GROUND CABLE AL WIRE 0.6/1KV CL.1 HD

Name: YAKY 5X 35.0 ŻO RE BLACK GROUND CABLE AL WIRE 0.6/1KV CL.1 HD
Brand: ELPAR
SKU: 795089
Availability: InStock

5217,30 € VAT incl.

VAT incl. (21%)

RRP price: 6156,58 €

Part No: YAKY-5X35-RE(ŻO)-1KV NAYY

Brand: ELPAR

Delivery time 3-5 working days.

For your home.

Fast support.

Additional information

Weight	1450 kg
Dimensions	1600 × 1600 × 900 mm
Nominal cross section conductor	35mm2
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Flame retardant	According to IEC/EN 60332-1-2
Circuit integrity	None
Nominal voltage U	1000V
Colour outer sheath	Black
Shape of conductor	Round
Diameter conductor	29.5mm
Conductor material	Aluminium
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 1 = solid
Armouring/reinforcement	None
Permitted cable outer temperature during assembling/handling	-5°C
Core colour	Several
Nominal voltage U0	600V
Number of cores	5
Max. conductor temperature	70°C
Protective barrier	None
Outer diameter approx.	29.5mm
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Min. permitted bending radius, stationary application/permanent installation	354mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Brand	ELPAR
SKU	795089
EAN	5901854412047
