ADC960D C10A/ 30MA/AC 1P+N DIFFERENTIAL CURRENT SWITCH C10A 2M 30MA AC 6KA

Name: ADC960D C10A/ 30MA/AC 1P+N DIFFERENTIAL CURRENT SWITCH C10A 2M 30MA AC 6KA
Brand: HAGER
SKU: 523326
Availability: InStock

54,35 € VAT incl.

VAT incl. (21%)

RRP price: 139,00 €

Part No: ADC960D

Brand: HAGER

6 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Description

RCBO WYŁĄCZNIK RÓŻNICOWOPRĄDOWY Z CZŁONEM NADPRĄDOWYM 1P+N 6KA C 10A/30MA TYP AC

Additional information

Weight	0,22 kg
Dimensions	100 × 80 × 40 mm
Voltage type	AC
Built-in depth	68mm
Rated current	10A
Rated voltage	240V
Release characteristic	C
Rated insulation voltage Ui	500V
Rated fault current	0.03A
Leakage current type	AC
Surge current capacity	0.25kA
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	2
Frequency	50 Hz
Degree of protection (IP)	IP2X
Number of protected poles	1
Rated short-circuit breaking capacity according to EN 60898	6kA
Rated short-circuit breaking capacity according to IEC 60947-2	6kA
Connectable conductor cross section solid-core	1mm2
Connectable conductor cross section multi-wired	1mm2
Ambient temperature during operating	-25°C
Number of poles (total)	2
Rated impulse withstand voltage Uimp	4kV
Rated short-circuit breaking capacity Icn according to EN 61009-1	6kA
Disconnection characteristic	Undelayed
Brand	HAGER
SKU	523326
EAN	3250611010876
