H05V-U DY 0.75 BLACK SINGLE CONDUCTOR WIRE 300/500V CL.1
142,49 € VAT incl.
H05V-U DY 0.5 BLACK SINGLE CONDUCTOR WIRE 300/500V CL.1
106,92 € VAT incl.
H05V-U DY 0.75 WHITE SINGLE CONDUCTOR WIRE 300/500V CL.1
140,19 € VAT incl.
- VAT excl.
115,86 € VAT excl.
VAT incl. (21%)
Part No:
G-105479
Brand:
TELE-FONIKA KABLE
Delivery
Delivery time 3-5 working days.
50k products
For your home.
Support
Fast support.
Quality
Top product brands.
Request the product
Description
Przewód jednożyłowy o izolacji polwinitowej, do układania na stałe.
Przewód przeznaczone do montowania wewnątrz urządzeń i w oprawach oświetleniowych.
Do układania na stałe w rurach instalacyjnych lub innych osłonach przewodów, wyłącznie do obwodów
sygnalizacyjnych lub sterujÄ…cych.
Additional information
| Weight | 11 kg |
|---|---|
| Dimensions | 150 × 150 × 70 mm |
| Nominal cross section conductor |
0.75mm2 |
| Material core insulation |
Polyvinyl chloride (PVC) |
| Core identification |
None |
| Weight |
10.91kg/km |
| Flame retardant |
According to IEC/EN 60332-1-2 |
| Nominal voltage U |
500V |
| Shape of conductor |
Round |
| Diameter conductor |
0.96mm |
| Conductor material |
Copper |
| Material outer sheath |
None |
| Conductor category |
Class 1 = solid |
| Armouring/reinforcement |
None |
| Permitted cable outer temperature during assembling/handling |
-15°C |
| Permitted cable outer temperature after assembling without vibration |
-40°C |
| Core colour |
White |
| Nominal voltage U0 |
300V |
| Number of cores |
1 |
| Max. conductor temperature |
70°C |
| Protective barrier |
None |
| Outer diameter approx. |
2.16mm |
| Conductor surface |
Bare |
| Reaction-to-fire according to EN 13501-6: Class |
Eca |
| Reaction-to-fire according to EN 13501-6: Smoke production |
None |
| Reaction-to-fire according to EN 13501-6: Flaming droplets/particles |
None |
| Reaction-to-fire according to EN 13501-6: Acidity |
None |
| Min. permitted bending radius, stationary application/permanent installation |
8.64mm |
| Specification core insulation |
Other |
| Specification material outer sheath |
Other |
| Cable geometry |
Round |
| Conductor resistance at 20 °C |
24.5Ω/km |
| Identification/coding colour core |
White |
| Brand | |
| SKU | 004502 |
| EAN | 5907802003640 |
