LC1D150P7 150A 3Z 1Z+1R POWER CONTACTOR 150A 3Z 1Z+1R 80KW 230V AC SCREW TERMINALS OR TERMINALS

Name: LC1D150P7 150A 3Z 1Z+1R POWER CONTACTOR 150A 3Z 1Z+1R 80KW 230V AC SCREW TERMINALS OR TERMINALS
Brand: SCHNEIDER ELECTRIC
SKU: 036236
Availability: InStock

365,89 € VAT incl.

VAT incl. (21%)

RRP price: 721,51 €

Part No: LC1D150P7

Brand: SCHNEIDER ELECTRIC

6 in stock

Add to wishlist

Compare

Delivery

Delivery time 3-5 working days.

50k products

For your home.

Support

Fast support.

Quality

Top product brands.

Description

Stycznik mocy I= 150A [AC-3], styki pom. 1NC+1NO, nap. cewki 230 V AC. Zakres: TeSys – typ produktu:

Additional information

Weight	2,488 kg
Dimensions	200 × 165 × 185 mm
Rated operation power at AC-3, 400 V	75kW
Number of normally open contacts as main contact	3
Number of normally closed contacts as main contact	0
Number of auxiliary contacts as normally open contact	1
Number of auxiliary contacts as normally closed contact	1
Rated operation current Ie at AC-3, 400 V	150A
Rated operation current Ie at AC-1, 400 V	200A
Rated control supply voltage AC 50 Hz	230V
Rated control supply voltage AC 60 Hz	230V
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	AC
Rated operation current Ie at AC-4, 400 V	50A
Rated operation power at AC-4, 400 V	22kW
Brand	SCHNEIDER ELECTRIC
SKU	036236
EAN	3389110476071
