OP20 SURGE ARRESTER T2 C 4P 4M 20/40KA 1.5KV TN
50,36 € VAT incl.
- VAT excl.
41,62 € VAT excl.
VAT incl. (21%)
Part No:
AM-111000-02
Brand:
ILUVE
861 in stock
Delivery
Delivery time 3-5 working days.
50k products
For your home.
Support
Fast support.
Quality
Top product brands.
Additional information
| Weight | 0,37 kg |
|---|---|
| Dimensions | 100 × 75 × 80 mm |
| Mounting method |
DIN rail (top hat rail) 35 mm |
| With remote signalling contact |
No |
| Number of conductors (without earthing) |
4 |
| Construction size |
4 modular spacing |
| Voltage protection level |
1.5kV |
| Max. continuous voltage AC |
275V |
| Nominal discharge surge current (8/20) |
40kA |
| Nominal voltage AC |
230V |
| Nominal voltage DC |
0V |
| Category type 2 |
Yes |
| Signalling at the device |
Optical |
| Integrated backup fuse |
No |
| Brand | |
| SKU | 605741 |
| EAN | 5901780733643 |
