SPA930 SPD T1+T2 MOV 3P surge arrester TN-C network Iimp=37.5kA In=50kA Up?1,2

Name: SPA930 SPD T1+T2 MOV 3P surge arrester TN-C network Iimp=37.5kA In=50kA Up?1,2
Brand: HAGER
SKU: 930223
Availability: InStock

272,19 € VAT incl.

VAT incl. (21%)

Part No: SPA930

Brand: HAGER

4 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,524 kg
Dimensions	80 × 60 × 60 mm
Mounting method	DIN rail (top hat rail) 35 mm
Number of poles	3
Construction size	3 modular spacing
Voltage protection level	1.2kV
Max. continuous voltage AC	335V
Nominal voltage AC	415V
Test class	Type 1 + 2
Voltage protection level L-N	1.2kV
Signalling at the device	Optical
Degree of protection (IP)	IP20
Voltage protection level N-PE	1.7kV
Max. conductor cross section solid (solid, stranded)	35mm2
Max. conductor cross section flexible (fine-strand)	25mm2
Specific energy (W/R)	39kJ/Ω
Voltage protection level L-PE	1.7kV
Max. overcurrent protection device, parallel connection (fuse)	160A
Max. overcurrent protection device, series connection (fuse)	80A
Brand	HAGER
SKU	930223
EAN	3250615515179
