STACKED INSTALLATION CONNECTOR WITH PUSH BUTTON 2.5 MM2, GRAY

Name: STACKED INSTALLATION CONNECTOR WITH PUSH BUTTON 2.5 MM2, GRAY
Brand: WAGO
SKU: 3041176
Availability: InStock

4,39 € VAT incl.

VAT incl. (21%)

Part No: 2203-7646

Brand: WAGO

4984 in stock

Delivery time 3-5 working days.

For your home.

Fast support.

Top product brands.

Additional information

Weight	0,016 kg
Dimensions	5 × 80 × 40 mm
Mounting method	DIN rail (top hat rail) 35 mm
Rated voltage	400V
Operating temperature	105°C
Inflammability class of insulation material according to with UL94	V0
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Number of potentials	3
Basic colour	Grey
Connectable conductor cross section solid-core	0.75mm2
Connectable conductor cross section fine-strand with cable end sleeve	0.75mm2
Connectable conductor cross section fine-strand without cable end sleeve	0.25mm2
Connectable conductor cross section multi-wired	0.25mm2
Material insulation body	Thermoplastic
Rated current In	31A
Brand	WAGO
SKU	3041176
EAN	4066966121957
